Bevel gear 3034.00-V02EXXXHXXX

Product Description

This gear unit is designed to be used for many different mechanical drive solutions. Applications of adjustment for: steppless height-adjustable desks, umbrellas, adjustable windows, partition walls, etc. and any kind of linear adjustment in the industrial machinery industry.

Special features
very slim size, square 25.8
Ratio 1:1
Housing made of reinforced glass-fibre
Case hardened toothed wheels of steel, reinforced teeth.
Output bevel-wheel running in ball bearings.
Support tube round Ø 20 mm; or square 22 mm
Especially suitable for the driving with Ketterer motors.

Customer specific
The gear can be supplied with various spindle lengths and spindle pitches. Different types of support tubes are available.

Caution
Please take into account that depending on the spindle pitch, the system could back-drive.

* in combination with motor drive 3133 and LogicData control box Compact-3

Ratio Input Support tube Stroke max. Type of spindle Max. drive torque Max. lifting force
1:1 hex 6 mm square 22 mm retracted length 100 mm SG14x16P4 RH 4 Nm 700 N
