Bevel gear 4803
Product Description
Gear for stepless height adjustment for sit-sit or sit-stand workplaces.
Special features
The output bearing can be loaded on pressure. A special toothing ensures a smooth running of the gear.
Ratio 2:1
Housing made of zinc die-casting
Case hardened bevel wheels
Customer specific
The gear can be supplied in combination with various spindles. If you employ e-motors, the bearing point of the bearings has to be equipped with glycodur bearings.
Caution
Please take into account that depending on the spindle pitch, the system could back-drive.
| Ratio | Input | Number of bevel wheels | Max. drive torque | Max. lifting force |
|---|---|---|---|---|
| 2 : 1 | hex 6 mm | 3 | 4 Nm | 1200 N |
