Jubilee® Clips - 304 / A2 Stainless Steel
Product Description
The most versatile of clips in the Jubilee® range, our Original Range Jubilee® hose clips in 304 (18/8) stainless steel are widely used across all industries where hose clips are used to secure hoses, as well as for other applications. Their corrosion resistance enables their use in the marine, oil and gas and food sectors, as well as the agricultural, hardware and industrial sectors, where higher corrosion resistance is required.
| Product Code | Diameter (mm) | Band Width (mm) | Recommended Torque (Nm) | Maximum Torque (Nm) | Maximum Pressure (Psi) | Pricei | Stock | Pack Sizei | No. of Packs |
|---|---|---|---|---|---|---|---|---|---|
| JC-A2-000 | 9.5 - 12 | 9.9 | 3.4 | 4.5 | 203 | £11.05 | 100 |
5
|
|
| JC-A2-M00 | 11 - 16 | 9.9 | 3.4 | 4.5 | 203 | £11.11 | 100 |
5
|
|
| JC-A2-00 | 13 - 20 | 9.9 | 3.4 | 4.5 | 203 | £11.22 | 150 |
5
|
|
| JC-A2-0 | 16 - 22 | 13 | 4.2 | 5.6 | 203 | £13.65 | 250 |
5
|
|
| JC-A2-0X | 18 - 25 | 13 | 4.2 | 5.6 | 203 | £13.65 | 400 |
5
|
|
| JC-A2-1A | 22 - 30 | 13 | 5.1 | 6.8 | 203 | £15.00 | 90 |
5
|
|
| JC-A2-1 | 25 - 35 | 13 | 5.1 | 6.8 | 102 | £15.46 | 50 |
5
|
|
| JC-A2-1X | 30 - 40 | 13 | 5.1 | 6.8 | 102 | £15.94 | 60 |
5
|
|
| JC-A2-1M | 32 - 45 | 13 | 5.1 | 6.8 | 102 | £16.63 | 60 |
5
|
|
| JC-A2-2A | 35 - 50 | 13 | 5.9 | 7.9 | 102 | £17.67 | 60 |
5
|
|
| JC-A2-2 | 40 - 55 | 13 | 5.9 | 7.9 | 102 | £18.58 | 40 |
5
|
|
| JC-A2-2X | 45 - 60 | 13 | 5.9 | 7.9 | 102 | £19.42 | 90 |
5
|
|
| JC-A2-3 | 55 - 70 | 13 | 6.7 | 9 | 102 | £20.76 | 60 |
5
|
|
| JC-A2-3X | 60 - 80 | 13 | 6.7 | 9 | 44 | £22.09 | 60 |
5
|
|
| JC-A2-4 | 70 - 90 | 13 | 6.7 | 9 | 44 | £23.20 | 30 |
5
|
|
| JC-A2-4X | 85 - 100 | 13 | 6.7 | 9 | 44 | £24.52 | 50 |
5
|
|
| JC-A2-5 | 90 - 120 | 13 | 6.7 | 9 | 44 | £26.65 | 50 |
5
|
|
| JC-A2-6 | 110 - 140 | 13 | 6.7 | 9 | 44 | £28.58 | 50 |
5
|
|
| JC-A2-6X | 120 - 150 | 13 | 6.7 | 9 | 18 | £30.40 | 55 |
5
|
|
| JC-A2-7 | 135 - 165 | 13 | 5.9 | 7.9 | 18 | £32.30 | 15 |
5
|
|
| JC-A2-7.5 | 158 - 190 | 13 | 5.9 | 7.9 | 18 | £35.80 | 15 |
5
|
|
| JC-A2-8.5 | 184 - 216 | 13 | 5.9 | 7.9 | 18 | £40.69 | 25 |
5
|
|
| JC-A2-9.5 | 210 - 242 | 13 | 5.9 | 7.9 | 18 | £45.78 | 30 |
5
|
|
| JC-A2-10.5 | 235 - 267 | 13 | 5.9 | 7.9 | 18 | £49.88 | 65 |
5
|
|
| JC-A2-11.5 | 260 - 292 | 13 | 5.9 | 7.9 | 18 | £53.16 | 30 |
5
|
|
| JC-A2-12.5 | 286 - 318 | 13 | 5.9 | 7.9 | 18 | £56.07 | 25 |
5
|
